Mixmeister Controller LED Midi Info…

Anyone interested in using this controller for other software such as Traktor or VDJ I figured out 85% of the mapping for the led’s… The reason I say 85% is because the edit controls and pitch shift lights are constantly on… You probably can control them via Bomes or something but for general use this the blue print… Also the strip solo lights has 2 different colors (green and amber) but the info I posted are for green… You can play around and figure out the info for amber.

Hope this helps.

[Nosferatu]

what did you use to get this info?.. this is good stuff!

[DJ_Urkel_Dee]

The long tedious way, I picked a function and went down the list of midi notes. But programs like Bomes can get it done also.

[Nosferatu]

I finally have some time to sit and work on my mapping. Thanks again for this info… this was a tremendous amount of work!

[JesC]

Thanks for the picture Urkel Dee. I did a quick mod edit so everyone can see the picture.

BTW im sure you remember me, I bought the X1 from you last year.

[EquaLies]

I’ve added the amber notes to the original image:

this thread has really helped me get my personal set up going

[DJ_Urkel_Dee]

No problem Nosferatu

Thanks JesC & EquaLies…
