Traktor // Presonus Firebox // VCI-100 // iTunes

DJTT Gear & Custom Mods DJ TechTools' VCI-100 Product Support
1

Traktor // Presonus Firebox // VCI-100 // iTunes

Here’s what I want to do:

Traktor Pro using VCI-100 controls, output to a club mixer (at venue) using Firebox.

I can’t get it to work and the Presonus is sounding really bright (treble) - more than usual.

I saw the “how-to” on the forum, but the Firebox Control panel doesn’t even look the same as the screen shot that is posted. Also, is there a way to have iTunes play on one of the channels or is that out of the question?

HELP PLEASE.

2

Send me a screenshot of your firebox mixer settings and traktor pro soundcard settings (input and ouput), and the info where what is connected to the firebox (speakers or amp or whatever).
Then I can help you.

I’m using a vci-100, traktor pro and the presonus firebox.

3

THANKS!
Here are screen shots of what the options are on my screen, also attached a photo of the cables I am using - the cables might be a problem too because I have a hard time hearing in stereo without switching up the cables to some weird combination that makes no sense.

I would like to know how I can set up with both internal mixer and external - if i go external, then I can’t use the ProX Fade that I installed the way I want to. :slight_smile:

Thank you in advance for your help.

4

Please note - the setup I am needing help with is for MAC platform.

5

Hi there,

the way your mixer is setup go for these Traktor Pro settings and report back.

external (output)

Output Monitor
L 3:Lineout 3L
R 4:Lineout 4R

Output Master
L 1:Mainout 1L
R 2:Mainout 2R

If that doesn’t work I can post my complete settings, which you can then try out for yourself and if they solve the problem work towards your own setup.

6

Leon, I will definitely try this tonight. Will this allow me to use the VCI mixer controls?

Thank you so much for your time.

7

Oh yeah,

I noticed you have the settings set to external mixing.
In addition to the settings I already mentioned you also have to set:

Output Routing

Mixing mode:
internal

Greetings and good luck:slight_smile:

8

Hi Leon,
Everything seems to be well except for one thing - the headphone cueing…
the headphone cue buttons (on the VCI-100 SE) as well as the fade (master & program volumes) & level knobs, when pressed or turned, the levels are affected on the main output into the mixer.

does that makes sense? i wish you were here. :slight_smile:

9

something is backwards. maybe you should send me your screen shots if you don’t mind.

10

Gimme a sec to get my screen shots, I will see if I can help you out.

11

The first pic is my firebox mixer settings when I use Traktor Pro

1024×640 169 KB

The next pic is my settings for traktor pro when I mix internal. I haven’t mixed externally as of yet.
These settings seem to only work in Tpro. When I use iTunes I have to switch the settings in the firebox mixer.

1024×640 135 KB

I hope this helps you, and if you find out how to make traktor and iTunes work together please let me know.

12

This is how I have to set the firebox mixer for iTunes to work.

1024×640 168 KB

13

Hi Goldith,

if yo set your headphones to channel 3/4 in the firebox mixer settings (far right “playback to phones”) everything should work.

When cueing you have set the mix level of the headphones in Traktor Pro.
You can find these settings along with with master volume in upper middle section of traktor pro (not in the options/settings window - in the main window).

PS: I can’t send you my settings until the weekend but I think the posted should solve your problems.
